vLLM, TensorRT-LLM & Inference Engines

The Inference Engine Landscape

You could theoretically run inference with plain PyTorch and Hugging Face, but you'd get 5–10% GPU utilization. Production inference engines exist to solve the hard systems problems: memory management, scheduling, parallelism, and kernel optimization.

vLLM Deep Dive

PagedAttention — The Core Innovation

vLLM's key insight: GPU memory fragmentation was the #1 bottleneck before vLLM. Traditional systems pre-allocate a contiguous chunk for each request's KV cache. This wastes up to 60% of VRAM due to fragmentation and over-allocation.

# Start vLLM OpenAI-compatible server
python -m vllm.entrypoints.openai.api_server     --model meta-llama/Meta-Llama-3.1-8B-Instruct     --dtype bfloat16     --max-model-len 8192     --gpu-memory-utilization 0.90     --max-num-seqs 256     --enable-prefix-caching     --tensor-parallel-size 1     --port 8000

Key vLLM Configuration Parameters

Tensor Parallelism in vLLM

For models too large for one GPU, vLLM supports tensor parallelism (splitting weight matrices across GPUs). Each GPU computes a subset of the attention heads and MLP outputs, communicating via all-reduce operations.

python -m vllm.entrypoints.openai.api_server     --model meta-llama/Meta-Llama-3.1-70B-Instruct     --tensor-parallel-size 4   # split across 4 GPUs
    --dtype bfloat16     --gpu-memory-utilization 0.92

Automatic Prefix Caching

When multiple requests share the same system prompt prefix (common in chatbots), vLLM can reuse the KV cache blocks for that prefix. Hash-based matching identifies shared prefixes. Cache hit = skip the entire prefill for that prefix = huge TTFT reduction.

Flash Attention

Flash Attention is an algorithmic improvement to the attention mechanism that's now standard in all production inference engines. Traditional attention loads the full Q×K matrix into VRAM; Flash Attention tiles this computation in SRAM, dramatically reducing memory bandwidth usage.

• Flash Attention 1 (2022): 2–4x speedup on attention, O(N) memory instead of O(N²)
• Flash Attention 2 (2023): Better GPU utilization, improved parallelism across sequence length
• Flash Attention 3 (2024): H100-specific optimizations using FP8, asynchronous pipeline, 2.6x speedup vs FA2
• vLLM, SGLang, TRT-LLM all use FA2/FA3 by default

TensorRT-LLM

NVIDIA's own inference engine, built for maximum performance on NVIDIA hardware. Less flexible than vLLM but faster on NVIDIA GPUs for production deployments, especially with custom CUDA kernels.

TRT-LLM Architecture

• Compilation step: Model is compiled into a TensorRT engine (.plan file) — startup cost, but inference is highly optimized
• In-flight batching: Same continuous batching as vLLM, implemented as "inflight batching"
• Custom kernels: Heavily optimized CUDA kernels for attention, layer norms, activations
• FP8 first-class support: NVIDIA's Transformer Engine with FP8 is best in class on H100
• Paged KV cache: Similar to vLLM's PagedAttention

import tensorrt_llm
from tensorrt_llm.runtime import ModelRunner

runner = ModelRunner.from_dir(
    engine_dir="./engine",
    rank=0,
    max_output_len=512,
)

outputs = runner.generate(
    batch_input_ids=input_ids,
    sampling_config=sampling_config,
)

vLLM vs TensorRT-LLM

SGLang — The Third Option

SGLang (Structured Generation Language) is a newer inference engine from LMSYS (the team behind Vicuna and Chatbot Arena). It's increasingly popular for workloads that involve structured outputs, multi-call programs, or complex sampling patterns.

• RadixAttention: SGLang's answer to PagedAttention — uses a radix tree to share KV cache across requests with common prefixes more aggressively than vLLM
• Structured decoding: native support for JSON schema-constrained generation (faster than outlines/guidance)
• Multi-call programs: chain multiple LLM calls in a single request without round-trip overhead
• Comparable throughput to vLLM on most benchmarks, sometimes faster for prefix-heavy workloads

Deploying vLLM Behind an API Gateway

from openai import OpenAI

# vLLM exposes OpenAI-compatible endpoint
client = OpenAI(
    base_url="http://your-vllm-host:8000/v1",
    api_key="not-needed"
)

response = client.chat.completions.create(
    model="meta-llama/Meta-Llama-3.1-8B-Instruct",
    messages=[{"role": "user", "content": "Explain KV caching"}],
    max_tokens=512,
    temperature=0.1,
    stream=True,
)
